Z-Series Heat Pump System 3 Ton 17.7 SEER2 12 EER2 10 HSPF2 R454B
Z-Series Heat Pump System 3 Ton 17.7 SEER2 12 EER2 10 HSPF2 R454B
Regular price
$9,964.89 USD
Regular price
Sale price
$9,964.89 USD
Unit price
per
Couldn't load pickup availability
- High-Efficiency Performance – Achieves 17.5–19 SEER2, meeting ENERGY STAR® certification and qualifying for tax credits and rebates.
- Match with the Z-Series self-Identifying 115/230V Air Handler – Indoor unit automatically detects voltage and operates on either 115V or 230V upon installation.
- 10 Year Parts & Compressor Warranty, no registration required.
- Optional Communicating Touchscreen Thermostat (sold separately)– Z-Series communicating thermostat features a sleek, modern design and maintains variable speed and peak efficiency for optimal comfort and energy savings.
- Simplified Retrofit Installation – A2L sensor control requires only two wires for indoor-to-outdoor connectivity, making installation easier for contractors. Also, the indoor unit measures as a standard 14.5, 17.5, 21.5 cabinet width.
Brand Name AC Pro MFG Name AC Pro MFG Model ID SPHP-Z-V036BB MFG Product ID SPHP-Z-V036BB AC Pro Item ID 84233 Width 37.25 Inches Depth 16.13 Inches Height 31.8 Inches Weight 204.15 Warranty Details 10 Year Compressor~10 Year Parts dB Rating 63 EER2 12.0 HSPF2 10 Liquid Line Size 3/8 Inches Manufacturer Group Z-Series Max Amps 30 Min Amps 26 Phase Single Refrigerant Type R454B Region California~Arizona~Nevada~Utah SEER2 17.7 Stages Variable Suction Line Size 3/4 Inches Tonnage 3 Type Heat Pump Voltage 230 AC Weight 204.15 Pounds
Z-Series Air Handler Multi Position 3 Ton 115/208/230V 17.5" wide R454B RDS Included
- Self-Identifying 115 or 230V Air Handler – Indoor unit automatically detects voltage and operates on either 115V or 230V upon installation.
- Optional Communicating Touchscreen Thermostat (sold separately) – Z-Series communicating thermostat features a sleek, modern design and maintains variable speed and peak efficiency for optimal comfort and energy savings.
- 10 Year Parts & Compressor Warranty, no registration required.
- Z-Series Air Handler includes a 24V hard-wired thermostat and handheld remote. The wired thermostat functions as an IR Receiver for the handheld remote, if the remote is not used it must be retained with the indoor unit to adjust parameters, and for troubleshooting.
- These air handlers are pre-charged with a low amount of nitrogen or helium to prevent dirt and moisture from entering the piping system.
Brand Name AC Pro MFG Name AC Pro MFG Model ID AIRH-Z-V036V12C MFG Product ID AIRH-Z-V036V12C AC Pro Item ID 84228 Color Gray Width 17.52 Inches Depth 21.50 Inches Height 53.98 Inches Weight 149.25 Warranty Details 10 Year Compressor~10 Year Parts Application Residential CFM 1236 Liquid Line Size 3/8 Inches Manufacturer Group Z-Series Max Amps 15 Min Amps 6.0 Phase Single Refrigerant Type R454B Region California~Arizona~Nevada~Utah Speed Variable Suction Line Size 3/4 Inches Tonnage 3 Voltage 115 AC~230 AC Weight 149.25 Pounds
